"REAL TIME" GPS and FUEL MONITORING
- SPECIAL MACHINERY "REAL TIME" GPS and FUEL
MONITORING
|
|
| |
|
Vehicle and Special
Machinery "Real Time" GPS and Fuel Monitoring (GSM/GPRS):
- operative
real time monitoring the moving of transport and its
location over the GSM network;
- remotely collection information about vehicle movement, driver activity
and fuel consumption.
Connectivity
GuardMagic GSM-GPRS modules (GuardMagic VB series)
to external additional sensors, such us engine
immobilisers, fuel level sensors, temperature
sensors, alarm buttons, driver identification,
vehicle alarm system etc. is facilitated through the
onboard I/O lines.
Industrial
(professional) EIA-485 communication interface also
provide connection and collection data from fuel
level sensor with very high accuracy (1024 or 4096
levels) with detection status of communication line.
GuardMagic VB
vehicle modules have "Multi Tanks" functionality
(allow to support up to THREE vehicle regular fuel
tanks).
|
|
|
/gps-gprs%20monitoring.01.jpg) |
-
remote
wireless vehicle monitoring;
-
wireless
transmitting data by GSM/GPRS network;
-
day and night
automatic vehicle monitoring;
-
"real time"
monitor vehicle position;
-
monitoring
vehicle movement parameters;
-
"real time"
monitor fuel level in regular vehicle tanks;
-
fix fuel draining
and refueling;
-
monitor fuel
consumption and fuel usage;
-
"real time"
monitoring status of external sensors;
-
driver
identification;
-
immobilization
function;
-
storing
information in internal memory when "out of
GSM coverage" or "GSM network busy" for
posterior data transmitting;
-
worldwide
cover operation
|
In general
System consist of next main components:
-
GuardMagic
VB3 ;
(or GuardMagic VB6,
GuardMagic VF1, GuardMagic
VF2)
Vehicle GPS/GPRS module
|
GuardMagic VB module consist
of: GPS receiver,
GSM/GPRS modem chip,
internal memory,
microcontroller board.
Based on satellite GPS
signal GuardMagic
VB calculate its
location (coordinates
of vehicle) and parameters
of vehicle movement, collect
information from external
sensors and send this
information to monitoring
station.
( or, Storing the GPS data
and data from external
sensor and circuits in
internal non-volatile memory
and posterior transmitting
this information to
monitoring station).
|
-
GuardMagic DLLS1;
Robust digital fuel level sensor with
communication interface EIA-485
|
Make
measurement of fuel level in
fuel tank and send fuel level
code to main module |
|
|
For connection fuel level
sensor to main module.
|
-
Communication network (GSM/GPRS
+ Internet)
|
Communication channel for the
sending information from vehicle
module to monitoring station
(special WEB server or Personal
Computer with monitoring
software). |
|
|
Monitoring Station (special WEB
server or Personal Computer with
monitoring software) collect and
store all information from
vehicle modules, make analyzing
of this data, visualize vehicle
location and vehicle route on
electronic map, generate reports
about vehicle activities.
|
* Main Notes:
GuardMagic VF1 module has not fuel monitoring
functionality.
Using the
information transmitting by GuardMagic VB
module about vehicle, vehicle location,
information from external sensors is possible
to:
-
check the current
location of vehicle;
-
check the whole
track of the transport movement and the optimality
of route;
-
check parameters of
movement and real trip of transport;
-
always have a real
information about fuel in fuel tanks;
-
check real fuel
consumption;
-
check up volume of
fueled fuel and determine the fact of fuel drain;
-
personalize the
active driver;
-
determine start/end
of loading/unloading of a vehicle;
-
check the use of
working hours;
-
check the visited
points;
-
check the
performance of the job or analyze the reason of job
failure.
|
|
